impression Laser – Product Data

• Manual Files: files/products/impression-laser-product-data/impressionLaser_Manual_V1.2_EN.pdf
• DMX Charts: files/products/impression-laser-product-data/DMX_impression_Laser_v1.1.pdf
• Header Image:
• Product Picture Gallery:



  impression Laser

• Product info:
  • Long product text (editor):

    The GLP impression Laser is a Pure Diode laser projector in RGB and inspires all those who move with the times; those who always want to be one step ahead and never stand still. Small, handy, light - this is how this head-mounted show laser powerhouse can be attached to the truss and fits unobtrusively, but certainly strikingly into the show concept.

    Every laser show - whether beam show or laser graphics - is precisely positioned on any projection surface by the moving head. The moving head is conveniently controlled via DMX, the laser output is via ILDA. Individual and creative laser shows are made possible by the professional and world-renowned LPS-RealTIME Pro laser show software.

    The GLP impression laser is available in 3 W and 6 W RGB.

    , Short product description: The GLP impression Laser is a Pure Diode laser projector in RGB
• Aufbau:
  • Daten enthalten?: ja , Eigenschaften: Lasermodule: 680 mW red (638 nm), 1.000 mW green (520 nm) | Betriebsmodi: ILDA, TEC | Scanner: X/Y Laser Scanner 60 kkps (60°), Scanner Safety | Software (optional): LPSA-RealTIME Pro Lasershowsoftware
• Maße & Gewicht:
  • Daten enthalten?: ja , Tiefe (Kopf gerade hoch): 145 mm / 5.7 in, Höhe (Kopf gerade hoch): 370 mm / 14.56, Gewicht (netto): 8 kg / 17.6 lbs, Breite (über Kopf): 340 mm / 13.38
• Elektrische Spezifikationen:
  • Daten enthalten?: ja , Netzanschluss Input: 100 – 240 VAC / 50 – 60 Hz , max. Leistung (@ 230 V): 410 W
• Installation:
  • Daten enthalten?: ja , Befestigung: 2 Ösen für Sicherungskabel, M10 Gewinde, Omega Bracket , Ausrichtung: beliebig
• Bewegung:
  • Daten enthalten?: ja , Pan Angle: 660°, 8 – 16 Bit, Position correction system: Position feedback , Tilt Angle: 280°, 8 – 16 Bit
• Thermische Spezifikationen:
  • Daten enthalten?: ja , max. Umgebungstemperatur: 40 °C / 104 °F
• Construction:
  • Construction features: Lasermodule: 680 mW red (638 nm), 1.000 mW green (520 nm) | Operating modes: ILDA, TEC | Scanner: X/Y Laser Scanner 60 kkps (60°), Scanner Safety | Software (optional): LPSA-RealTIME Pro Lasershowsoftware
• Movement:
  • Pan Angle: 660°, 8 – 16 Bit, Position correction system: Position feedback , Tilt Angle: 280°, 8 – 16 Bit
• Electrical Specifications:
  • Power Input: 100 – 240 VAC / 50 – 60 Hz , max. Power (@ 230 V): 410 W
• Installation:
  • Mounting: 2 eyelets for safety cable, M10 thread, Omega Bracket , Orientation: any
• Dimensions & Weight:
  • Depth (head straight up): 145 mm / 5.7 in, Height (head straight up): 370 mm / 14.56, Weight (netto): 8 kg / 17.6 lbs, Width (across yoke): 340 mm / 13.38
• Thermal Specifications:
  • max. ambient temperature: 40 °C / 104 °F
